TSC · T8000
TSC T8000 4-Inch Enterprise Industrial Printer
Enterprise-grade 4-inch industrial printer, supports 24/7 operation, optional ODV-2D barcode verification, ideal for demanding production environments.
- 24/7 non-stop operation
- Optional ODV-2D barcode verification
- Color touchscreen display
- Interchangeable 203/300 dpi printheads
- Wi-Fi 802.11 a/b/g/n support
203 / 300 dpi
Resolution
14 ips
Print Speed
104 mm
Print Width
3.5" color LCD
Display
Full Specifications
TSC · T8000Print Specifications
5 items- Print Method
- Direct Thermal / Thermal Transfer
- Resolution
- T8204: 203 dpi (8 dots/mm); T8304: 300 dpi (12 dots/mm)
- Print Speed
- T8204: 356 mm/s (14 ips) @ 203 dpi; T8304: 305 mm/s (12 ips) @ 300 dpi
- Print Width
- 104 mm (4.1")
- Min Label Length
- 6.35 mm (0.25") continuous paper; 25.4 mm (1") tear/peel/cutter
Hardware
1 items- Memory
- 512 MB RAM / 128 MB Flash
Media Specifications
3 items- Media Types
- Continuous paper/die-cut labels/folding
- Media Width
- Max 114.3 mm (4.5")
- Media Core
- 38 – 76 mm (1.5" – 3")
Ribbon Specifications
2 items- Ribbon Length
- Max 625 m
- Ribbon Width
- Max 114.3 mm (4.5")
Interface & Software
2 items- Interface
- USB 2.0 + RS-232 Serial + Ethernet; optional Parallel IEEE1284 + GPIO + Wi-Fi 802.11 a/b/g/n dual-band
- Programming Language
- Supports 9 competing printer language emulations (including TSPL, PGL, ZPL, PostScript/PDF)
General
3 items- Display
- 3.5" full-color LCD + buttons, graphic operation panel with setting wizard
- Construction
- Die-cast aluminum alloy frame and printing mechanism, steel upper cover, large transparent observation window
- Options
- Heavy duty cutter
